Features
- Input voltage: AC100-250V
- Operating frequency: 50/60Hz
- Power factor: ! 0.90
- Ambient temperature range: -20°C ~+40°C
- Color Temp: 3000K~5000K
- THD: <20%
- IP Rating: IP20
- CRI: >80Ra
- Beam angle: 120°
- Cover: Suitable to use in UL approved Clear, Stripy
- Luminous Flux:>120lm/w
- Housing material:6063-T5
- Suitable for Damp Location
- Suitable to use in UL approved enclosed fixtures
- 5 years’ warranty
Mounting Guides
Electric Shock Attention
Ensure the power supply has been cut off before connecting the wire, and all wiring and installation of this product are required to be operated by professionals.
Installation Instruction
Step1: Place Clip Kits and Screws Correctly
Step2: Fix the LEd Tube to the Ceiling or Wall
Step3: Connect the Power Cord to the Tube
Step4: Connect by Linkable Connector
Caution: The integrated tubes can not be connected more than total pcs
For model zs-t8y0610 and ses-t8y1222, the max connecting quantity of tube is ≤8 pcs.
For model zs-t8y2445, the max connecting quantity of tube is ≤5 pcs.
For model zs-t8y2460, when using rated 125v/10a power supply wire, the max connecting quantity of tube is
≤5 pcs. When using rated 250v/2.5a power supply wire, the max connecting quantity of tube is ≤3 pcs
- Model: BL-FL30-50W-XX
- Description: 50W LED Flood Light
- Power: 50W
- Voltage Input: 100-277Vac,50 / 60HZ
- Lumen output: 5,500lm
- Color Temperature: 3,000K – 5,000K
- CRI: Ra>80
- Power Factor: >0.95
- Lens: Temper Glass
- Operating Temperature: -25℃~ 55℃
- LED Chips: Philips
- IP Rating: IP65
- Certificates: ETL/cETL , DLC
- warranty: 5 years
- L70 life span: >50000Hrs
- Housing Material: Aluminum
- Max.Input current: 0.95Amp@100Vac
- Dimmable: No
- Weight: 1.9 Kg (4.18 pound)
Adaptor Types (Unit:mm)
Container Loading QTY
Notice For User
1) Thread the floodlight mounting arm into the 1/2″ opening of the cover and secure it with 1/2″ locknut ( for Adaptor D only ).
2)
> Connect supply ground to luminaire ground (green).
> Connect supply common to luminaire neutral (white).
> Connect supply black to luminaire line(black).
> Pull connectors into Junction box.
3) Loosen the side bolt connected to the arm knuckle to aim the fixture up or down. Re-tighten bolt to secure the fixture in the desired position.
1. Disconnect power before installation, must operated by electrician
2. Take out the tube. Before installation please check if there is any unsatisfactory condition of the tube,
Such as whether the appearance is damaged or deformed, or the accessories are complete or not.
3. Please use it under correct input power range
4. This tube is non-dimmable
5. Not for outdoor or some where be exposed to rain(waterproof type available)
6. If the lights don’t work properly, please check the connections after turning off the power
7. Use ul approved 3-pin plug.
